Control Handle
Standard: AS2047
Design SLS
400Pa
SHGC Range
0.45–0.76
Water Resistance
150Pa
ULS
600Pa
U Range
3.5–5.5
Sound Insulation
<29dB
Production Configuration
Extrusion Profile
6063-T5, 2.0mm thickness
Opening Type
Hand-toggle operation
Thermal Break
Non-thermally broken (thermally broken series available on request)
Surface Treatment
Automotive-grade fluorocarbon spray, 15+ year quality guarantee
Regular Colours
Black and white (special colours available on request)
Sealing Strips
EPDM automotive-grade sealing strip
Glass Configuration
5mm + 12mm argon-filled gap + 5mm
Open Fan Size Limit
Height 3100mm · Width 1000mm
Maximum Adaptive Weight
10kG
Frame Profile Depth
101mm
Frame Profile Height
50mm
Hardware
China Brand / Doric / Customised
Installation Method
Timber reveal, fin fix, subhead, subsill or L angle — compatible with concrete, brick veneer, and light gauge steel + Hebel panel wall systems
Powder Coating
10–25 year warranty depending on finish (Dulux / Akzo Nobel / Interpon)
